Ortofon Stylus 10 Ersatznadel für OM10, Super OM10, OD1, OMP 10, TM 10
SKU
240753
Technische Daten:
- Frequency range: 20-24.000 Hz
- Frequency response: 20-20.000 Hz + 3 / - 1 dB
- Tracking ability at 315Hz at recommended tracking force*): 70 µm *) Typical value
- Compliance, dynamic, lateral: 25 µm/mN
- Stylus type: Elliptical
- Stylus tip radius: r/R 8/18 µm
- Tracking force range: 1.25-1.75 g (12.5-17.5 mN)
- Tracking force, recommended: 1.5 g (15 mN)
- Tracking angle: 20°
- Stylus colour: Black
- Recommended for following cartridges: Super OM 10, OM 10, OMP-mount 10, OMBulk 10, OMT 10, LM 10, Concorde 10, Concorde EC 10, Concorde STD, TM 10H, LMB 12, SMB 12, LMA 12
